MH 110 SIMPLEX / DUPLEX

MH series horizontal packaging machines are designed for the production of flat bags (3 or 4 seals) from a heat-sealable roll of packaging material. The machine can be used for packing small pieces, granular, light-flowing, heavy-flowing, pasty and liquid products.

Machine output:

up to 100 packs/ min. - SIMPLEX
up to 200 packs/ min. - DUPLEX

Dose size:
SIMPLEX
min. 35x35 mm
max. 110x130 mm
DUPLEX
Min. 35+35x35 mm
max. 65+65x130 mm

Personal introduction with designer over the phone

Bulk commodities:
salt, coffee, sugar and other products

Powder commodities:
ground spices, washing powder, cocoa, coffee, matcha and more

Liquid commodities:
ketchup, mustard, oil, cosmetics and other liquids

Piece commodities:
candies, frozen vegetables, pasta etc.

Filled and closed bag or double-bag with three or four sides welded leave the machine via a slide or an outfeed conveyor for further handling.

The machine has an electromechanical drive and a step operating cycle. Machine control is performed by the control system allowing easy setting of machine parameters.

CHARACTERISTIC
- Sealing type: thermal
- Packed products: loose, dusty, bite-sized, liquid, pasty
- Control: control panel
- Bag types: flat bags with 3 or 4 sealed sides, bag chains
- Machine drives: electromechanical
- Machine cycle: step
- Machine surface: varnished, stainless steel design
BAG TYPES
- Flat 4SS
- Flat 3SS
- Flat duplex 3SS
- Flat duplex 4SS
PARAMETERS
- Bag dimensions SIMPLEX (width x height): min. 35 x 35 mm / max. 110 x 130 mm
- Bag dimensions DUPLEX (width x height): min. 35+35x35 mm / max. 65+65x130 mm
- Machine dimensions (width x height x length): 990x1895x2245 mm
- Filled volume: SIMPLEX 1-60 cc / DUPLEX 1-20 cc
ACCESSORY
automatic dosing units according to product type - auger, volumetric, pumps
marking device
systems dust removal
easy opening
Euro hole punch system
zipper, closure applicators
different types of cutting blades
conveyor systems
DRAWING
